Indemar
Single Axis Valve Lever - Linear
- SKU:
- J-3047
- Availability:
- 2 - 5 Business Days
- Shipping:
- Calculated at Checkout
Frequently bought together:
Description
Compact design single lever, with die-cast body, suitable for any type of hydraulic valve. Controls can be banked together for multiple different hydraulic valve actuation. Other variants such as neutral lock or forward-reverse interlock can be considered. Compatible with Valve Cable J-731133-100. Handle can be positioned into 3 different holes for operator activation efficiency.
Features include:
- Lever is Self-Centering
- Lever Travel 12.5/12.5mm
- Lever Ration 9:1
- Stackable
- 3 Position Location for Lever
- Die-Cast Body
Custom We are happy to provide custom products upon request, simply click here to send an email with your requirements and details for a quick response from our sales team. NOTE: All Shipping via EXPRESS Post. For sales outside Australia, please use same email link to arrange your order.
